GB-Type-4SP-Hoses

SAE 100R17 types are one wire braided(sizes: 04 and 06) two wire braided hydraulic hoses. YH Hydraulic is professional in hydraulic hose production. We are manufacturing complete types and sizes of these hoses to meet different requirements from customers and industry. Many sizes of regularly used hoses are kept as stock to shorten delivery time.

Details


Part no.: SAE 100R17
Construction: This hose consists of an inner tube of oil synthetic rubber, a single or two wire braid reinforcement, an oil and weather resistant synthetic rubber cover.
Feature: Medium pressure 3000PSI for all sizes.
Samples policy: Less than 1 meter is free of charge for checking the quality according to stock condition.
Stock: we have kept many sizes and types as stock products to shorten delivery time.

Technical Data Table

名义直径

Nominal

Diameter

内径

Inside  diameter mm

钢丝层直径

Reinforcement

Diameter mm

外径

Outside diameter mm

工作压力working pressure MPa实验压力

Proof pressure

MPa

爆破压力burst pressure

MPa

最小弯曲

Min. bend

Radius

mm

MinMaxMinMaxMinMaxMaxMaxMin
6.31/46.27.010.011.013.221.042.084.050
85/167.78.511.813.015.021.042.084.055
103/89.310.113.815.017.021.042.084.065
12.51/215.513.517.418.821.121.042.084.090
165/812.316.722.023.625.921.042.084.0100
193/418.619.826.127.730.321.042.084.0120
25125.026.434.035.638.621.042.084.0150

Packing & Delivery


Normal packing
The general package of hydraulic hose is plastic or woven bag with pallet under the hose, which can be seen below. We, however, can also provide special package according to customer’s requests.
Customized packing
For your smooth business ,we can provide customized packing service . we can make label with your logo ,and print your trade mark on package, and goods.
Delivery Time

Normal Specification: usually 10-15 days;
Large quantity and various kinds: please negotiate.
Sample Time: Within 5 days for sample approval.
