2F9 adapter fittings are 90 degrees elbow ORFS male o-ring to ORFS female types. High pressure fluid-conducting swivel joints extend hose life as well as provide design versatility for simplified plumbing and ease of maintenance. Complete sizes of 2F9 fittings are manufactured in YH Hydraulic. YH insist on providing good quality products and lower prices.
Details
Part no.: 2F9(90°ORFS Male O-ring to ORFS Female)
Working pressure: maximum 3000 psi
Intended for use only in fluid power systems
Temperature range: -40°F to 200°F
Ports: o-ring face seal male; o-ring face seal female
Technical Data Table
| 代号 PART NO. | 螺纹THREAD | 尺寸 DIMENSIONS | ||||
| E | F | A | C | S1 | S2 | |
| 2F9-04 | U9/16"X18 | U9/16"X18 | 29 | 10 | 14 | 19 |
| 2F9-06 | U11/16"X16 | U11/16"X16 | 30 | 11 | 17 | 22 |
| 2F9-08 | U13/16"X16 | U13/16"X16 | 37 | 12 | 22 | 24 |
| 2F9-10 | U1"X14 | U1"X14 | 43 | 13.5 | 27 | 32 |
| 2F9-12 | U1.3/16"X12 | U1.3/16"X12 | 52 | 13.5 | 33 | 36 |
| 2F9-16 | U1.7/16"X12 | U1.7/16"X12 | 59 | 14.5 | 44 | 41 |
| 2F9-20 | U1.11/16"X12 | U1.11/16"X12 | 59 | 15.5 | 44 | 50 |
